In 1943/44, Krupp started production of the prototype, while full-scale production was to start in mid-1945, but the end of the war cancelled any further development. It was planned to mount 170mm K 72 L/50 gun and to have a maximum armor of 30 mm.
One prototype of Grille 17 was completed in May of 1945 and was captured by British troops at Haustenbeck near Paderborn.



Type: Self-Propelled Gun
Crew: 8
Production: 1 prototype

Maybach HL230P30 or HL230P45 Gasoline | 690 or 700 hp
Dimensions/Masses
Length: 13 m(with gun) | Width: 3.27 m | Height: 3.15 m
Weight: 58000 kg
Front Armor
Maximum: 30 mm - Minimum: 16 mm
Performances
Max. Speed: 45 km/h | Power/weight: 12.6 hp/t | Range: 250km.
Suspension: Torsion bars
Armament

Main: 170mm K 72 L/50 (5 rounds)
Secondary: 2 x 7.92 mm MG 34
