| Specifications |
| General |
| Role: Battleship Class: Kaiser Crew: 41 officers, 1043 enlisted men Launched: 10 June 1911 |
| General characteristics |
| Length: 172.4 m | Beam: 29 m | Draught: 9.10 m | Displacement: 27000 t |
| Propulsion |
| 3 shaft AEG-Curtis turbines, 42181 shp | three 3-blade propellers, 3.75 m diameter |
| Performances |
| Maximum speed: 22 knots (40.7 km/h) | Range: 14630 km at 12 knots (22 km/h) |
| Armor |
| 363.22 mm belt, 304.8 mm barbettes, 304.8 mm turrets, 63.5 mm decks |
| Armament |
| Main: 10 × 305 mm (12.0 in)/50 calibre guns
in 5 twin turrets Secondary armament: 14 × 150 mm (5.9 in)/45 caliber guns in single casement mounts 12 × 88 mm (3.5 in)/45 calibre guns in single mounts, 5 × 500 mm (20 in) underwater torpedo tubes |
