HEDRON-1, USMC - MCAS El Toro, circa 1951. Only model certified for aircraft-carrier use.





Specifications F7F-4
General

Type: Carrier-borne/Land-Based Night Fighter
Crew: 2
First flight: 2 November 1943
Number built: 13 built, 364 (all type)
Powerplant
2 × Pratt & Whitney R-2800-34W Double Wasp radial |
2100 hp each | Pistons
Dimensions/Masses
Length: 13.8 m | Wingspan: 15.7 m | Height: 5.1 m
Wing area: 42.3 m² | Empty weight: 7380 kg
Loaded weight: ? kg | Max takeoff weight: 11670 kg
Performances
Maximum speed: 740 km/h | Range: 1900 km
Service ceiling: 12300 m
Armament

Inside: 4 × 20 mm (0.79 in) M2 gun, 4 × .50 in (12.7 mm) M2 Browning MG
Outside: 2× hardpoints for up to 907 kg of bombs,
or 1 × torpedo under fuselage
